Adjustable roll square bottom paper bag making machinery Introduce In-touch screen human-machine interface, easy for correction and fine adjustment.
Alarm and working status can be displayed in screen on-line, easy for operation and maintenance.
Equipped with PLC for centralized control system and SICK photocell for correction, tracking the printed material accurately, minimize the adjustment and preset time, increase the production efficiency.
Human oriented security protection, whole housing design, ensure the safety of operator.
Physiosis roller hydraulic material loading system with chuck, hydraulic up/down system .
Automatic constant tension control for unwinding, EPC web guider system, motor for material feeding with inverter, minimize the adjustment time for web alignment.
High speed oriented design ensure successful of production: within the suitable paper range, production capacity can reach 150~180pcs/min, even higher, which increases the unit production capacity and gets higher profit.
Original SCHNEIDER electric system, ensure better stability and reliability; perfect after sale service, trouble free for customer.
* Paper bags machinery Speed will be variable due to different glue quality and operator’s skill.
* Bag Dimension, Adhesive Quality, Operator Knowledge, Moisture, Type and Basis weight of Paper Can affect Machine Speeds.
Adjustable roll to square bottom paper bag making machine has the advantage of fast making, high production efficiency ,large adjustment range, comprehensive domestic inadequate of similar products, then to improve the new equipment.
paper bag machine make the primary color or printed roll paper to glue on the side. Folded into a tube, glue on the bottom, bag bottom forming and export bags.
The machine is controlled by computer
central control system, touch screen display, the servo motor control the
length of paper bags, it can produce a variety of sizes paper bags,the fastest
can reach to 220 pcs/min paper bags , Garment shopping paper bags paper bag
making machinery greatly reducing the labor costs.
MODEL
SBR-290
Max. Diameter of Paper Rol
ф1500 mm
Width of Paper roll
320-930 mm
Internal Diameter of Roll Core
ф76 mm
Length of Bag
225-470 mm
Max.Speed
180 pcs/min
Width of Bag
120-280 mm
Total Power
15Kw
Width of Bag Bottom
60-160 mm
Weight of Machine
Approx 6500 kg
Paper weight
60-160 g/m2
Overall Dimension
L 8300 mm × W 2000 mm × H 1800 mm
1. Paper bag making machine Material feeding using hydraulic lift structure, unwinding using automatic tension control.
2. Side glue using the auto gluing system.
3. Correction using the pausource from Taiwan
4. Paper tube forming device include thumb-cut function
5. Automatic shutdown, when it run out of material
6. All of center clip, drum clamps and drum machines are suing spider synchronous adjustment mechanical design, it can significantly reduce the adjustment time to replace the size.
7. With Germany SICK photoelectric, accurately tracking the printed materials
8. Equipped with automatic lubrucation supply system, stoppage alarm system.
Hongying Machinery is a modern private enterprise integrating paper bag making machine scientific research ,development, manufacture, sales and auxilary.
With many years of expertise and experience of developing and producing the envelope paper bag series, food paper bag making machine series, shopping paper bag making machine series,
our company has strong technical strength and paper bag machine excellent processing equipment, So we enjoy the high reputation and credibility in the domestic and international paper bag making machine market.
Our paper bag machine products have been exported to Europe, the US, the Middle East, Southeast Asia, Hong Kong,Taiwan and other regions.
WHAT IS THE DIFFERENCE BETWEEN A POINTED BOTTOM PAPER BAG AND A SQUARE BOTTOM PAPER BAG ?
The pointed bottom paper bags and square bottom paper bags produced by the paper bag machine seem to have only minor differences in shape. In fact, there are significant differences in use, structure, design, and environmental protection.What is the maximum paper bag production speed of the paper bag machine ?
Generally speaking, the full-automatic handbag paper bag machine can produce up to 170 paper bags per minute, meeting the needs of all paper bag manufacturers. One square bottom paper bag machine can produce 10000 paper bags per hour.
Why choose environmentally friendly paper bags ?
Paper bags made of environmentally friendly raw material paper are very environmentally friendly，A growing number of countries are banning single-use plastic bags.
Paper bags are a more attractive and climate-smart smart alternative that don’t risk ending up in the oceans as hazardous litter.
